Skyjack SJ12 E Service Manual

150
SJ12 E, SJ16 E, SJ20 E
241914ACA
Section 5 – Procedures Display Module
JOYD 3:HORN OFF/ON Status of the Digital Input at the Platform Joystick for Horn
JOYD 4:DECK LIM OFF/ON Status of the Digital Input at the Platform Joystick for Deck Limit Switch
JOYD 5:SERVICE OFF/ON Status of the Digital Input at the Platform Joystick for Service Limit Switch
JOYD 6:FOOT KC OFF/ON Status of the Digital Input at the Platform Joystick for the Limit Switch
JOYD
7:PLATFORM
OFF/ON Status of the Digital Input at the Platform Joystick for the Platform Active Switch
JOYD 8:KC SWNO OFF/ON Status of the Digital Input at the Platform Joystick for the KC N/O
JOYD 9:KC SWNC OFF/ON Status of the Digital Input at the Platform Joystick for the KC N/C
JOYD10:INDOOR OFF/ON Status of the Digital Input at the Platform Joystick for the Indoor Mode Active
JOYD13:ENABLE OFF/ON Status of the Digital Input at the Platform Joystick for the Joystick Enable Switch
JOYD14:STEER L OFF/ON
Status of the Digital Input at the Platform Joystick for the Joystick Steer Left
Switch
JOYD15:STEER R OFF/ON
Status of the Digital Input at the Platform Joystick for the Joystick Steer Right
Switch
JOYSTICK: FAULT OFF/ON Joystick in fault state
JOYA 1: Y AXIS ANALOGUE (BYTE2)*256+(BYTE3) gives 0-65535 value representing 0V-5V
JOYO 1: LED 1 OFF/ON Status of the LED Output for Power ON
JOYO 2: LED 2 OFF/ON Status of the LED Output for Drive Mode
JOYO 3: LED 3 OFF/ON Status of the LED Output for Lift Mode
LOAD C. WEIGHT
1
WEIGHT
(Kg)
Weight measured at the Load Cell 1
LOAD C. WEIGHT
2
WEIGHT
(Kg)
Weight measured at the Load Cell 2
LOAD C. WEIGHT
3
WEIGHT
(Kg)
Weight measured at the Load Cell 3
LOAD C. ERROR OFF/ON see load cell protocol
LOAD C. MOTION OFF/ON see load cell protocol
LOAD C. W.10KG OFF/ON see load cell protocol
LOAD C. OVER W. OFF/ON see load cell protocol
LOAD C.UNDER
W.
OFF/ON see load cell protocol
LOAD C.R
WEIGHT1
WEIGHT
(Kg)
Weight measured at the Redundant Load Cell 1 (not always present)
LOAD C.R
WEIGHT2
WEIGHT
(Kg)
Weight measured at the Redundant Load Cell 2 (not always present)
LOAD C.R
WEIGHT3
WEIGHT
(Kg)
Weight measured at the Redundant Load Cell 3 (not always present)
LOAD C.R ERROR OFF/ON see load cell protocol
Name Unit of Measure Description
