Skyjack SJ12 E Service Manual

151
SJ12 E, SJ16 E, SJ20 E
241914ACA
Display Module Section 5 – Procedures
Name Unit of Measure Description
LOAD C.R
MOTION
OFF/ON see load cell protocol
LOAD C.R W.10KG OFF/ON see load cell protocol
LOAD C.R OVER
W.
OFF/ON see load cell protocol
LOAD C.R UNDER
W
OFF/ON see load cell protocol
CTRAP HW
Number
(1)
Slave motor: number of occurrences of hardware-detected overcurrent events.
CPU TIME F US Reserved Zapi internal use
CPU TIME US Reserved Zapi internal use
TILT PITCH
Degrees
(0.01°)
reading of the internal tilt sensor in degrees for the Pitch Angle
TILT ROLL
Degrees
(0.01°)
reading of the internal tilt sensor in degrees for the Roll Angle
TILT STATUS OFF/ON Tilt sensor status.
TILT
TEMPERATURE
Celsius
(0.1 °C)
Temperature of the internal Tilt Sensor
OUTDOOR MODE OFF/ON
status of the outdoor mode function:
OFF = indoor;
ON = outdoor
OVER HEIGHT
Number
(1)
status of the over height function:
0 = under height;
1 = over height;
2 = over height with over shot;
PULSE DOWN
STATE
Number
(1)
status of the pulse down function
