Skyjack SJ6826RT - Page 103

107
SJ6826RT, SJ6832RT
213560ABA
Electrical System Section 4 – Troubleshooting Information
4. Left Rear outrigger N.C.-held open limit switch LS68 is
out of adjustment or defective.
Check continuity from wire #10A and wire #68A through
switch when closed.
Adjust switch if out of adjustment.
Replace if defective.
5. Loose or broken wire #68A from outrigger limit switch
LS68 to outrigger control module pin #P2-1.
Check continuity. Replace if defective.
6. Loose or broken wire #10A from outrigger board to
outrigger down limit switch LS67.
Check continuity. Replace if defective.
7. Right Rear outrigger N.C.-held open limit switch LS67
is out of adjustment or defective.
Check continuity from wire #10A and wire #67A through
switch when closed.
Adjust switch if out of adjustment.
Replace if defective.
8. Loose or broken wire #67A from outrigger limit switch
LS67 to outrigger control module pin #P2-2.
Check continuity. Replace if defective.
9. Loose or broken wire #10A from outrigger board to
outrigger down limit switch LS66.
Check continuity. Replace if defective.
10. Right Front outrigger N.C.-held open limit switch LS66
is out of adjustment or defective.
Check continuity from wire #10A and wire #66A through
switch when closed.
Adjust switch if out of adjustment.
Replace if defective.
11. Loose or broken wire #66A from outrigger limit switch
LS66 to outrigger control module pin #P2-3.
Check continuity. Replace if defective.
12. Loose or broken wire #10A from outrigger board to
outrigger down limit switch LS65.
Check continuity. Replace if defective.
13. Left Front outrigger N.C.-held open limit switch LS65 is
out of adjustment or defective.
Check continuity from wire #10A and wire #65A through
switch when closed.
Adjust switch if out of adjustment.
Replace if defective.
14. Loose or broken wire #65A from outrigger limit switch
LS65 to outrigger control module pin #P2-4.
Check continuity. Replace if defective.
Check for output power for Lift Enable signal on wire #65
at outrigger control module at pin #P2-8.
If no voltage present, proceed to outrigger control
module troubleshooting.
15. Loose or broken wire #65 from outrigger control
module at pin P2-8 to Outrigger Lift Enable Relay
65CR.
Check continuity. Replace if defective.
