Section 4 – Troubleshooting Information Electrical System
4.2-38 Individual Outrigger Functions Inoperative (Auto-Level)
1. Loose or broken wire #71 to wire #78 (depending on
which outrigger function is not working) at Outrigger
Control Module OCM1 plug P4 pins 1-8.
Check connections of the outrigger function not working.
(refer to Section 5 for pin reference chart).
Replace if defective.
2. No output from Outrigger Control Module OCM1 at
plug P4 pins 1-8.
Cycle power off to reset the Outrigger Control Module
OCM1.
Turn power back on and retest outputs.
If problem persists, replace Outrigger Control Module
OCM1.
4.2-39 Auto-Level Inoperative
1. Loose or broken wire #35D from Outrigger Enable
switch S9A to Auto Level Mode switch S24.
Check continuity. Replace if defective.
2. Defective Level Auto Mode switch S24.
Operate switch.
Check continuity between wire #35D and wire #70 on
switch when Level selected.
Replace if defective.
3. Loose or broken wire #70 from Auto Level Mode
switch S24 to Outrigger Control Module OCM1 pin
#P2-5 (Auto Level signal).
Check continuity. Replace if defective.
4. Loose or broken wire #10A from pin #4 on connector
CN14 of outrigger board to Outrigger Control Module
OCM1 pin #P2-12. (Power signal)
Check for power at P2-12.
If no voltage present, check continuity of wire.
Replace if defective.
5. Loose or broken wire #44 from pin #6 on connector
CN14 of outrigger board to Outrigger Control Module
OCM1 pin #P2-10. (Tilt Override/High Drive Cutout
signal)
Check for power at P2-10.
If no voltage present, check continuity of wire.
Replace if defective.
6. Loose or broken wire #02 from pin #8/9 on connector
CN14 of outrigger board to Outrigger Control Module
OCM1 pin # P2-11. (Battery negative – signal)
Check for ground at P2-11.
If no ground present, check continuity of wire.
Replace if defective.
For additional information, refer to sections 4 & 5 Outrigger Control Module – Troubleshooting
