SJ6826RT, SJ6832RT
213560ABA
2.5 Torque Specications
Cartridge
Torque Size
8 38 58 10 12 16
Lb-ft (max) 20 25 35 50
Lb-in (max) 240 300 420 600
Nm (max) 27.12 33.9 47.46 67.8
Coils
Torque
Size
All Coils
Lb-ft (max) 4 to 5
Lb-in (max) 48 to 60
Nm (max) 5.42 to 6.78
SAE Plugs
Torque Size
2 4 5 6 8 10 12 16
Lb-ft (max) 3 10 15 25 30 35
Lb-in (max)
36 120 180 300 360 420
Nm (max)
4.07 13.56 20.34 33.9 40.68 47.46
Bolts
Type of Bolt Torque (ft-lb) Torque (Nm)
Directional valve mounting bolts
2.33 (28-32 in-lb) 3.16 - 3.61
Wheel mounting bolts
90 122
Wheel motor castle nut (front)
350 474.54
Wheel motor castle nut (back)
350 474.54
Center drive sprocket mounting bolts
110 - 115 (242 Loctite) 149 - 156
Hydraulic drive motor mounting bolts
120 (242 Loctite) 162
Positive battery post cable/fuse nut
7.5 (90 in-lb) 10.2
Newton-meter = Nm
Foot-Pound Force = ft-lb Inch-Pound Force = in-lb
