Skyjack SJ6826RT - Outrigger Mechanical Limit Switch Wiring Diagram

163
SJ6826RT, SJ6832RT
213560ABA
Outriggers Section 5 – Procedures
5.4-9 Outrigger Mechanical Limit Switch
Wiring Diagram
O.R. UP SWITCH (NO) - BLUE & BROWN
BACK VIEW - MALE
O.R. UP SWITCH (NO) - BLUE & BROWN
O.R. UP SWITCH (NO) - BLUE & BROWN
O.R. DOWN SWITCH (NC) - BLACK & BLACK / WHITE
1
23
4
1
2 3
4
PIN 1 - BLACK
PIN 2 - BLACK / WHITE
PIN 3 - BLUE
PIN 4 - BROWN
BACK VIEW - MALE
1
23
4
PIN 1 - BLACK
PIN 2 - BLACK / WHITE
PIN 3 - BLUE
PIN 4 - BROWN
BACK VIEW - MALE
1
23
4
PIN 1 - BLACK
PIN 2 - BLACK / WHITE
PIN 3 - BLUE
PIN 4 - BROWN
BACK VIEW - MALE
1
23
4
PIN 1 - BLACK
PIN 2 - BLACK / WHITE
PIN 3 - BLUE
PIN 4 - BROWN
BACK VIEW - FEMALE
1
2 3
4
BACK VIEW - FEMALE
LEFT FRONT OUTRIGGER
1
2 3
4
BACK VIEW - FEMALE
LEFT REAR OUTRIGGER
RIGHT FRONT OUTRIGGER
1
2 3
4
BACK VIEW - FEMALE
RIGHT REAR OUTRIGGER
O.R. DOWN SWITCH (NC) - BLACK & BLACK / WHITE
O.R. UP SWITCH (NO) - BLUE & BROWN
LEFT FRONT OUTRIGGER SECTION VIEW
(SHOWN IN THE RETRACTED STATE)
RIGHT FRONT OUTRIGGER SECTION VIEW
(SHOWN IN THE RETRACTED STATE)
O.R. DOWN SWITCH (NC) - BLACK & BLACK / WHITE
O.R. DOWN SWITCH (NC) - BLACK & BLACK / WHITE
LEFT REAR OUTRIGGER SECTION VIEW
(SHOWN IN THE RETRACTED STATE)
RIGHT REAR OUTRIGGER SECTION VIEW
(SHOWN IN THE RETRACTED STATE)
SIXTEEN PIN CONNECTOR PLUG
OUTRIGGER PCB ON ELECTRICAL PANEL
TO CONTROL MODULE
PIN 1 - 65 GREEN / BLACK
PIN 2 - 65A WHITE
PIN 3 - 66A WHITE
PIN 4 - 67A WHITE
PIN 5 - 68A WHITE
PIN 6 - (N/U)
LEFT REAR
RIGHT REAR
RIGHT FRONT
LEFT FRONT
PIN 1 - 61
PIN 2 - 62 GREEN
PIN 3 - 62 RED
PIN 4 - 63 GREEN
PIN 5 - 63 RED
PIN 6 - 64 GREEN
PIN 7 - 64 RED
PIN 8 - N/U
PIN 9 - 10A BLACK (2x)
PIN 10 - 10A BLACK (2x)
PIN 11 - 10A BLACK (2x)
PIN 12 - 10A BLACK (2x)
PIN 13 - 10A GREEN
PIN 14 - N/U
PIN 15 - N/U
PIN 16 - 65 GREEN/BLACK
PIN 2 - WHITE (65A)
PIN 4 - RED (36)
PIN 1 - BLACK (10A)
PIN 3 - GREEN (62)
PIN 1 - BLACK (10A)
PIN 3 - GREEN (63)
PIN 2 - WHITE (66A)
PIN 4 - RED (62)
PIN 1 - BLACK (10A)
PIN 3 - GREEN (64)
PIN 2 - WHITE (67A)
PIN 4 - RED (63)
PIN 1 - BLACK (10A)
PIN 3 - GREEN (10A)
PIN 2 - WHITE (68A)
PIN 4 - RED (64)
