158
SJ6826RT, SJ6832RT
213560ABA
Section 5 – Procedures Outriggers
5.4-6 Outrigger Control Module (OCM1) Instructions
When an EZcal hand-held device is connected to the OCM1, a two line display shows various menus and settings.
At any time the top line of the display describes the currently selected menu. The bottom line shows the currently
selected item in that menu.
Six buttons on EZcal allow easy navigation through the menus:
and change the selected item (the bottom line display)
ENTER enters the selected new menu when available (top line display changes)
and adjusts the selected item when available
ESC exits the current menu back to the previous menu
Top Level Menu Options
Help Select This Menu To See A Description Of Current OCM1 Status
Diagnostics Select this menu to see switch input status and logged data
Access Level Select this menu and enter correct code to enable adjustments and calibrations
Adjustments
Select This menu to see and adjust OCM1 settings.
NOTE: this menu provides adjustments which may be needed for different work
activities
Setups
Select this menu to carry out initial set-up of the OCM1.
NOTE: This menu provides set-ups needed to congure the OCM1 for a particular
vehicle.
Help Menu Options
(help message)
A message displays current OCM1 status, indicating if everything is OK or if there is
an error code (Refer to 5.4-3 Auto-Leveling Outrigger Settings and Error Codes)
Diagnostic Menu Options
System Select this menu to see general OCM1 system information.
Switches Select this menu to see switch input status
Outputs Select this menu to see OCM1 output status
Log Select this menu to see logged information
Diagnostic/ System Menu Options
Outriggers Displays various status during the auto-level function
Tilt Displays vehicle tilt in X and Y orientations measured by integral sensor
Tilted Displays whether vehicle is tilted (YES or NO)
Battery Displays battery supply voltage (on P2-12)
