Outriggers Section 5 – Procedures
Diagnostic/Switches Menu Options
LR/P2-1 High when the left rear outrigger is in contact with the ground.
RR/P2-2 High when the right rear outrigger is in contact with the ground
RF/P2-3 High when the right front outrigger is in contact with the ground
EXTEND/P2-5 High to activate the auto-level function
RETRACT/P2-6 High to activate the auto-retract function
ELEV/P2-10
High when the scissor stack is stowed (elevated input indicates that the vehicle is
stowed).
Diagnostic/Outputs Menu Options
LAMP/P2-7 Displays state of outrigger control box light
STABLE/P2-8 Displays state of stable (all legs touching the ground) output
TILT/P2-9 Displays state of tilt
LRe/P4-1 Displays state of left rear outrigger extend valve
RRe/P4-2 Displays state of right rear outrigger extend valve
RFe/P4-3 Displays state of right front outrigger extend valve
LFe/P4-4 Displays state of left front outrigger extend valve
LRr/P4-5 Displays state of left rear outrigger retract valve
RRr/P4-6 Displays state of right rear outrigger retract valve
RFr/P4-7 Displays state of right front outrigger retract valve
LFr/P4-8 Displays state of left front outrigger retract valve
P4-9 MON
Displays the voltage to the outrigger valve (can only be seen when operating in auto-
level or retract)
Diagnostic/Log Menu Options
MAX.BATTERY Displays maximum recorded battery supply voltage
OCM1 version Displays part number and software version of GP106
EZcal version Displays software version of EZcal
Access Level Menu Options
CODE xxxx
ACCESS LEVEL 3 (allows viewing only)
ACCESS LEVEL 2 (allows setup on OCM1)
