Skyjack SJ6826RT - 4.2-5 Engine Does not Crank from Platform nor Base Control Console

87
SJ6826RT, SJ6832RT
213560ABA
Electrical System Section 4 – Troubleshooting Information
28. Defective Temperature switch TPS1.
Check switch.
Check continuity between wire #2C and wire #00 on
switch when closed.
Replace if defective.
29. Loose or broken wire #00 from Temperature switch
TPS1 to Engine GND (-).
Check continuity.
Replace if defective.
4.2-5 Engine Does not Crank from Platform nor Base Control Console
1. Loose or broken wire #08 from Horn switch S8 to
Engine Start switch S15 (Platform only).
Check for 12 volts on wire #08 starting at Platform
Emergency Stop switch S4 jumping to all switches.
Check continuity of wire #08. Replace defective portion.
2. Defective Engine Start switch S15 (Platform only).
Close switch.
Check continuity between wire #08 and wire #32 on
switch.
Replace if defective.
3. Loose or broken wire #32 from Engine Start switch
S15 to Engine Start switch S32 (Platform only).
Check continuity. Replace if defective.
4. Open or defective Idle/PLTF/Base Key switch S10.
(Base only)
Select function with switch.
Check continuity between wire #05 and wire #07 on
switch. (Platform selected).
Check continuity between wire #05 and wire #10E on
switch. (Base selected).
Replace switch if no continuity during correct switch
function.
5. Loose or broken wire #10E from Idle/PLTF/Base Key
switch S10 to Base terminal block TB-1 (Base only).
Check continuity. Replace if defective.
6. Open or defective diode D10E at Base terminal block
TB-1 (Base only).
Check diode. Replace if defective.
7. Defective Engine Glow Plug/Choke switch S13
(Platform only).
Operate switch.
Check continuity between wire #08 and wire #31 on
switch.
Replace if defective.
8. Loose or broken wire #31 from Engine Glow Plug/
Choke switch S13 to Engine Glow Plug/Choke switch
S31 (Platform only).
Check continuity. Replace if defective.
