88
SJ6826RT, SJ6832RT
213560ABA
Section 4 – Troubleshooting Information Electrical System
9. Loose or broken wire #10B from Base terminal block
TB-1 to Engine Glow Plug/Choke switch S31(Base
only).
Check continuity. Replace if defective.
10. Loose or broken wire #10B from Engine Glow Plug/
Choke switch S31 to Engine Start switch S32 (Base
only).
Check continuity. Replace if defective.
11. Defective Engine Start switch S32 (Base only).
Operate switch.
Check continuity between wire #32 and wire #10B on
switch.
Replace if defective.
12. Loose or broken wire #32 from Engine Start switch
S32 to Start Relay 32CR2.
Check continuity. Replace if defective.
13. Defective Start Relay 32CR2. Check Relay. Replace if defective.
14. Loose or broken wire #41 from Anti-Start Relay 32CR1
to Start Relay 32CR2 and Power Relay10CR2.
Check continuity. Replace if defective.
15. Loose or broken wire #02 from Start Relay 32CR2 to
Base terminal block TB-1.
Check continuity. Replace if defective.
16. Loose or broken wire #02 from Relay 10CR2 to Base
terminal block TB-1.
Check continuity. Replace if defective.
17. Open contact for ground not getting through N/C set of
contacts on Relay 10CR2.
Check continuity between wire #02 and wire #41 on
Relay.
Replace if defective.
18. Loose or broken wire #3A from Relay 10BCR to Anti-
Start Relay 32CR1.
Check continuity. Replace if defective.
19. Loose or broken wire #3A from Anti-Start Relay 32CR1
to Base Emergency Stop switch S6.
Check continuity. Replace if defective.
20. Loose or broken wire #3A from Base Emergency Stop
switch S6 to Engine Harness.
Check continuity. Replace if defective.
21. Loose or broken wire #32A from Anti-Start Relay
32CR1 to Engine Harness.
Check continuity. Replace if defective.
22. Loose or broken wire #32 from Start Relay 32CR2 to
Anti-Start Relay 32CR1.
Check continuity. Replace if defective.
23. Defective Anti-Start Relay 32CR1. Check Relay. Replace if defective.
24. Loose or broken wire #32A from Engine Harness to
Starter Contactor 32ACR.
Check continuity. Replace if defective.
