Skyjack SJ6826RT - 24 Platform Does Not Lift from Platform or Base Control Console with Outriggers Extended

106
SJ6826RT, SJ6832RT
213560ABA
Section 4 – Troubleshooting Information Electrical System
7. Right rear outrigger N.O.-held closed limit switch LS63
is out of adjustment or defective.
Check continuity from wire #64 and wire #63 through
switch when closed.
Adjust switch if out of adjustment.
Replace if defective.
8. Loose or broken wire #63 from outrigger limit switch
LS63 to outrigger board.
Check continuity. Replace if defective.
9. Loose or broken wire #63 from outrigger board to
outrigger limit switch LS62.
Check continuity. Replace if defective.
10. Right front outrigger N.O.-held closed limit switch LS62
is out of adjustment or defective.
Check continuity from wire #63 and wire #62 through
switch when closed.
Adjust switch if out of adjustment.
Replace if defective.
11. Loose or broken wire #62 from outrigger limit switch
LS62 to outrigger board.
Check continuity. Replace if defective.
12. Loose or broken wire #62 from outrigger board to
outrigger limit switch LS61.
Check continuity. Replace if defective.
13. Left front outrigger N.O.-held closed limit switch LS61
is out of adjustment or defective.
Check continuity from wire #62 and wire #36 through
switch when closed.
Adjust switch if out of adjustment.
Replace if defective.
14. Loose or broken wire #36 from outrigger limit switch
LS61 to outrigger board.
Check continuity. Replace if defective.
15. Open diode D36 on outrigger board. Check diode. Replace if defective.
16. Open diode D36-1 at pin #1 on CN22 on outrigger
board.
Check diode. Replace if defective.
4.2-24 Platform does not Lift from Platform or Base Control Console with Outriggers
Extended
1. Outriggers not extended enough.
Extend outriggers to take weight off tires (refer to
operator section).
2. Loose or broken wire #10A from Base terminal block
TB-1 to pin #4 on connector CN14 at the outrigger
board.
Check continuity. Replace if defective.
3. Loose or broken wire #10A from outrigger board CN22
to outrigger down limit switch LS68.
Check continuity. Replace if defective.
