121
SJ6826RT, SJ6832RT
213560ABA
Electrical System Section 4 – Troubleshooting Information
4.2-40 Auto All Up Inoperative (Retract)
1. Loose or broken wire #35D from Outrigger Enable
switch S9A to Auto Level Mode switch S24.
Check continuity. Replace if defective.
2. Defective Level Auto Mode switch S24.
Operate switch. Check continuity between wire #35D
and wire #79 on switch when ALL UP selected. Replace
if defective.
3. Loose or broken wire #79 from Auto Level Mode
switch S24 to Outrigger Control Module OCM1 pin
#P2-6 (ALL UP signal).
Check continuity. Replace if defective.
4. Loose or broken wire #10A from pin #4 on connector
CN14 of outrigger board to Outrigger Control Module
OCM1 pin #P2-12. (Power signal)
Check for power at P2-12. If no voltage present, check
continuity of wire. Replace if defective.
5. Loose or broken wire #44 from pin #6 on connector
CN14 of outrigger board to Outrigger Control Module
OCM1 pin #P2-10. (Tilt Override/High Drive Cutout
signal)
Check for power at P2-10. If no voltage present, check
continuity of wire. Replace if defective.
6. Loose or broken wire #02 from pin #8/9 on connector
CN14 of outrigger board to Outrigger Control Module
OCM1 pin # P2-11. (Battery negative – signal)
Check for ground at P2-11. If no ground present, check
continuity of wire. Replace if defective.
For additional information, refer to sections 4 & 5 Outrigger Control Module
