91
SJ6826RT, SJ6832RT
213560ABA
Electrical System Section 4 – Troubleshooting Information
14. Loose or broken wire #31A from Choke Relay 31CR to
Choke Solenoid CS-31A.
Check continuity. Replace if defective.
15. Loose or broken wire #02 from Choke Solenoid CS-
31A to Engine Harness.
Check continuity. Replace if defective.
16. Defective Choke Solenoid CS-31A. Check coils. Replace if defective
4.2-8 Glow Plugs Inoperative from neither Engine Controls nor Platform (Diesel
Models)
1. Loose or broken wire #08 from Lift/Off/Drive switch S3
to Glow Plug/Choke switch S13 (Platform only).
Check for 12 volts on wire #08 starting at Platform
Emergency Stop switch S4 jumping to all switches.
Check continuity of wire #08.
Replace defective portion.
2. Defective Glow Plug/Choke switch S13 (Platform only).
Operate switch.
Check continuity between wire #08 and wire #31 on
switch.
Replace if defective.
3. Loose or broken wire #31 from Glow Plug/Choke
switch S13 to Engine Glow Plug/Choke switch S31
(Platform only).
Check continuity. Replace if defective.
4. Loose or broken wire #10B from Base terminal block
TB-1 to Engine Glow Plug/Choke switch S31 (Base
only).
Check continuity. Replace if defective.
5. Defective Engine Glow Plug/Choke switch S31 (Base
only).
Operate switch.
Check continuity between wire #31 and wire #10B on
switch.
Replace if defective.
6. Loose or broken wire #31 from Engine Glow Plug/
Choke switch S31 to Engine Harness.
Check continuity. Replace if defective.
7. Loose or broken wire #31 from Engine Harness to
Glow Plug Relay 31CR.
Check continuity. Replace if defective.
8. Loose or broken wire #02 from Glow Plug Relay 31CR
to Engine Harness.
Check continuity. Replace if defective.
9. Loose or broken wire #103 from Main Power
Disconnect switch S1 to Glow Plug Relay 31CR.
Check continuity. Replace if defective.
10. Loose or broken wire #91A from Glow Plug Relay
31CR to Engine Glow Plugs EGP1.
Check continuity. Replace if defective
