113
SJ6826RT, SJ6832RT
213560ABA
Electrical System Section 4 – Troubleshooting Information
4.2-30 All Outriggers Inoperative (Auto-Level and Manual)
WARNING
Scissor lift must be below the Tilt Override/High Drive Cutout switch LS5 for outriggers to function.
NOTE: For the outriggers to function the Platform’s upper control box Lift/Off/Drive switch S3 must be in Lift mode and
the Scissor Stack stowed or fully retracted down
1. Loose or broken wire #44 from Base terminal
block TB-1 to pin #6 on connector CN14 of
outrigger board. (Tilt Override/High Drive
Cutout signal)
Check for power at connector. Replace if defective.
2. Loose or broken wire #09 from Base Terminal block
TB-1 to pin #5 on connector CN14 on outrigger board.
(Outrigger Enable signal)
Check for power at connector. Replace if defective.
3. Loose or broken wire #02 from Base terminal block
TB-1 to pin #8/#9 on connector CN14 on outrigger
board. (Battery negative – wire)
Check for continuity. Replace if defective.
4. Defective Outrigger Enable Relay 9CR2 and/or
Outrigger Proof Relay 9CR3 on outrigger board.
Check relays. Replace if defective.
5. Loose or broken wire #10A from Base Terminal block
TB-1 to pin #4 on connector CN14 on outrigger board.
(Main Power signal)
Check for power at connector. Replace if defective.
6. Defective Outrigger Lift Disable Relay 17DCR on
outrigger board.
Check relay. Replace if defective.
7. Open or defective Fuse Jumper J17E on outrigger
board.
Check fuse. Replace if defective.
8. Loose or broken wire #17B from pin #2 on connector
CN14 on outrigger board to Base terminal block TB-1.
(Large Pump Dump Valve solenoid “On” signal)
Check for continuity. Replace if defective.
9. Open diode D17C-1 on outrigger board. Check diode. Replace if defective.
10. Loose or broken wire #17C at pin #1 and/or wire #02
at pin #2 on connector CN21 on outrigger board to
outrigger Holding Valve solenoid 2H-17C.
Check for continuity. Replace if defective.
11. Defective outrigger Holding Valve solenoid 2H-17C. Check coil. Replace if defective.
