Skyjack SJ6826RT - 3.4 Hydraulic Parts List

45
SJ6826RT, SJ6832RT
213560ABA
Hydraulic Parts List Section 3 – System Component Identication and Schematics
3.4 Hydraulic Parts List
Index
No.
Skyjack
Part No.
Qty. Description
C1 220455 1 CYLINDER, Lift (Lower)
C2 220455 1 CYLINDER, Lift (Upper)
C7 135896 1 CYLINDER, Steer
C8 107752 1 CYLINDER, Cushion
C9 132694 1 CYLINDER, Outrigger (Front left)
C10 132694 1 CYLINDER, Outrigger (Front right)
C11 132694 1 CYLINDER, Outrigger (Rear right)
C12 132694 1 CYLINDER, Outrigger (Rear left)
CB1 137181 1 VALVE, Counterbalance (Main)
CB2 137181 1 VALVE, Counterbalance (Parallel)
CV1 104624 1 VALVE, Check
CV2 104624 1 VALVE, Check
CV3 104624 1 VALVE, Pilot check
CV4 104624 1 VALVE, Pilot check
CV5 104624 1 VALVE, Pilot check
CV6 104624 1 VALVE, Pilot check
CV7 104115 1 VALVE, Pilot check
CV8 104115 1 VALVE, Pilot check
CV9 104115 1 VALVE, Pilot check
CV10 104115 1 VALVE, Pilot check
F1 136408 1 FILTER ASSEMBLY
FD1 169282 1 VALVE, Flow divider
HP2 110652 1 PUMP, Brake hand
2H-13 107271 1 VALVE, Control (Lowering)
2H-13-1 210298 1 VALVE, Holding (Lower cylinder)
2H-13-2 125915 1 VALVE, Holding (Upper cylinder)
2H-17A 114365 1 VALVE, Control (Large pump dump)
2H-17C 103655 1 VALVE, Holding (Outrigger)
2H-18B 103656 1 VALVE, Control (Small pump dump)
2H-20B 106272 1 VALVE, Control (High speed)
2H-86D 103655 1 VALVE, Control (Hydraulic generator)
3H-14A 106273 1 VALVE, Control (Lift)
3H-30 103623 1 VALVE, Control (Brake)
4H-15A 128321 1 VALVE, Control (Reverse drive)
2H-15B 153337 1 VALVE, Control (Parallel reverse drive)
4H-16A 128321 1 VALVE, Control (Forward drive)
4H-16B 153337 1 VALVE, Control (Parallel forward drive)
