SJ6826RT, SJ6832RT
213560ABA
Section 3 – System Component Identication and Schematics Hydraulic Parts List
Index
No.
Skyjack
Part No.
Qty. Description
4H-20A 139351 1 VALVE, Control (Series/Parallel)
4H-23 153337 1 VALVE, Control (Right steer)
4H-24 153337 1 VALVE, Control (Left steer)
4H-71 153337 1 VALVE, Control (Front left outrigger retract)
4H-72 153337 1 VALVE, Control (Front right outrigger retract)
4H-73 153337 1 VALVE, Control (Rear right outrigger retract)
4H-74 153337 1 VALVE, Control (Rear left outrigger retract)
4H-75 153337 1 VALVE, Control (Front left outrigger extend)
4H-76 153337 1 VALVE, Control (Extend outrigger right front)
4H-77 153337 1 VALVE, Control (Extend outrigger right rear)
4H-78 153337 1 VALVE, Control (Extend outrigger left rear)
M1 137479 1 MOTOR (Front left)
M2 137479 1 MOTOR (Front right)
M3 137479 1 MOTOR (Rear right)
M4 137479 1 MOTOR (Rear left)
MB1 137215 1 BLOCK, Manifold (Main)
MB2
MB3 130443 1 BLOCK, Manifold (Lower holding valve) - KC
210297 1 BLOCK, Manifold (Lower holding valve)
MB4 108778 1 BLOCK, Manifold (Upper holding valve)
MB5 140898 1 BLOCK, Manifold (Sandwich)
MB6 139450 1 BLOCK, Manifold (Splitter)
MB7
MB8 111970 1 BLOCK, Manifold (Outrigger)
MB9 146082 1 BLOCK, Manifold (Hydraulic generator)
MB10 194323 1 BLOCK, Manifold (Flow Control)
O1 105281 1 ORIFICE (0.067 diameter)
O2 137510 AR ORIFICE, Lowering (0.106 diameter) (Model 6826RT)
137509 AR ORIFICE, Lowering (0.089 diameter) (Model 6832RT)
O3 137510 AR ORIFICE, Lowering (0.106 diameter) (Model 6826RT)
137509 AR ORIFICE, Lowering (0.089 diameter) (Model 6832RT)
O4 137508 2 ORIFICE, Brake (0.028 diameter)
P1 161943 1 PUMP, Dual hydraulic (11/6.4)
R1 104534 1 VALVE, Relief (System)
R2 104534 1 VALVE, Relief (Lift)
R3 106557 1 VALVE, Relief (Lift cylinder)
R4 106557 1 VALVE, Relief (Lift cylinder)
R5 104534 1 VALVE, Relief (Drive)
V1 107271 1 VALVE, Emergency lowering
V2 137182 1 VALVE, Freewheel
V6 113752 1 VALVE, Brake auto reset
