Models SJ6826 RT SJ6832 RT
Weight (Without Outriggers)* 2930 kg (6460 lb) 3443 kg (7590 lb)
Weight (With Outriggers)* 3440 kg (7570 lb) 3641 kg (8030 lb)
Overall Width 1765 mm (69.5 in)
Overall Length (Platform Retracted) 2720 mm (107 in)
Overall Length (Platform Extended) 4110 mm (162 in)
Platform Length, Inside (Platform Retracted) 2440 mm (96 in)
Platform Length, Inside (Platform Extended) 3900 mm (153 in)
Height
Working Height 9.7 m (31.7 ft) 11.5 m (37.6 ft)
Platform Elevated Height 7.8 m (25.7 ft) 9.6 m (31.6 ft)
Stowed Height (Railings Up) 2370 mm (93.5 in) 2510 mm (99 in)
Stowed Height (Railings Down) 1620 mm (63.5 in) 1750 mm (69 in)
Drive Height (Maximum) 7.8 m (25.7 ft) 9.6 m (31.6 ft)
Standard Operating Times
Lift Time (No Load) 32 - 36 sec
Lower Time (No Load) 46 - 50 sec 44 - 48 sec
Lift Time (Rated Load) 34 - 38 sec 37 - 41 sec
Lower Time (Rated Load) 34 - 38 sec
Chassis
Drive Speed (Stowed) 5.78 - 6.10 km/h (3.59 - 3.79 mph)
Drive Speed (Elevated) 0.52 - 0.61 km/h (0.32 - 0.38 mph)
Gradeability (Torque Equivalent To) 50 % 40 %
Tires (Foam Filled) 30.5 cm (12 in) x 66 cm (26 in)
Engine (RPM)
Kubota Diesel/Dual Fuel 3500 (High Throttle)/2050 (Low Throttle)
Fuel Tank Capacity 80 L (21 gal)
Hydraulic Oil
Type ATF
Tank Capacity 86.88 L (22.95 gal)
1704AA
* Weights are approximate; refer to serial nameplate for specific weight.
