Skyjack SJ6826RT - LED Error Codes - Code Breakdown Chart

171
SJ6826RT, SJ6832RT
213560ABA
Load Sensing System Section 5 – Procedures
5.5-6 LED Error Codes – Code Breakdown Chart
LED Flash Code Description Action
63
No Last Caldate
An EZcal is required!
62
Load Not Calibrated
61
Height Not Calibration
55
Waiting For Neutral
Check inputs on P2 pins 1,2,3,4,5,6,7,8.
56
Drive/Lift Inputs Faulty!
54
Up/Down Select Inputs Active To-
gether
52
EMS Inputs Faulty!
42 P3-4 Short To Supply!
Disconnect plug P3. If fault clears there is a problem
with the wiring from P3–4 or P3–6 to the rest of the
vehicle.
44 P3-4 Short To Supply?
46 P3-6 Short To Supply?
23 Armguard Active!
If the 23 ash code is triggered by armguard, it will
occur once then clean. This is not a true fault but just
an indication of the reason for the vehicle stop. If the 21
or 22 ash code is triggered by a fault with the elevation
switch, it does not clear. Check that the elevation switch
correctly opens/closes when the platform is raised/
lowered.
21 Elevation Switch Shifted?
22 Elevation Switch Stuck?
43 P3-4 Short To 0 V?
Disconnect plug P3. If fault clears there is a wiring
fault from P3-4 or P3-6 to the rest of the vehicle.
45 P3-6 Short To 0 V?
45 Invalid Load – Check Sensors Check the voltage out of the pressure transducer,
into P4-2. It should be between 0.5 V (zero pressure)
and 4.5 V (maximum pressure) and should vary as
the platform load & position varies.
52 Waiting For B+ on P2-12 Check that the battery voltage is not too low.
Verify battery voltage on P2-12.
Disconnect plug P4 – if the fault clears there is a wiring
fault from P4-1 to the rest of the vehicle.
51 B+ Supply Too Low
41 P4-1 Or P5-1 Short To 0V?
