Section 2 – Maintenance Tables and Diagrams Floor loading pressure
2.7 Floor loading pressure
Models
Total MEWP
Weight
Total MEWP Load
Wheel/Outrigger
Pad***
LCP** OUP**
kg lb kg lb kPa psi kg/m
2
psf
SJ6826 RT on tires
(foam-filled only)
min* 2930 6460 1400 3090 1130 163 620 125
max* 3440 7570 1630 3600 1310 190 730 150
SJ6826 RT on
outrigger pads
min* 3436 7573 1400 3090 280 40 590 119
max* 4003 8823 1630 3600 320 46 680 138
SJ6832 RT on tires
(foam-filled only)
min* 3443 7589 1675 3693 1350 195 720 146
max* 3897 8589 1860 4100 1500 216 920 166
SJ6832 RT on
outrigger pads
min* 3641 8027 1675 3693 330 47 620 126
max* 4095 9027 1860 4100 370 52 700 142
min: MEWP weight, LCP, and OUP with no options.
* max: MEWP weight, LCP, and OUP with options and full capacity on platform.
**
LCP: Locally Concentrated Pressure is a measure of how hard the MEWP presses on the areas in direct
contact with the floor. The floor covering (tile, carpet, for example) must be able to withstand more that the indicated
values above.
** OUP: Overall Uniform Pressure is a measure of the average load the MEWP imparts on the whole surface
directly underneath it. The structure of the operating surface (beams, for example) must be able to withstand more
than the indicated values above.
Note:
The LCP or OUP that an individual surface can withstand varies from structure to structure and is generally
determined by the engineer or architect for that particular structure.
***
Min wheel load is taken as 25% of the total weight of the model with no load on the platform. Max wheel load is
defined by measurement–the platform was fully elevated with the rated load located above one rear wheel.
1852AA
NOTE
The LCP or OFL that an individual surface can withstand varies from structure to structure and is
generally determined by the engineer or architect for that particular structure.
WARNING
Do not use tires other than the tires that Skyjack
specifies for this MEWP. Do not mix different types
of tires or use tires that are not in good condition.
Only replace the tires with the same types that are
approved by Skyjack. The use of other tires can
make the MEWP less stable. If you do not obey,
there is a risk of death or serious injury.
