172
SJ6826RT, SJ6832RT
213560ABA
Section 5 – Procedures Load Sensing System
5.5-7 LED Error Codes – Code Breakdown Chart (Continued)
LED Flash Code Description Action
11 Vehicle Tilted
These are not true faults but an indication that vehicle
movement is prevented. Remove excessive load from
the platform. Lower the platform if close to maximum
height. Move the vehicle to level ground.
12 Vehicle Overloaded
14 Too High – Drive Prevented
15 Too High – Lift Up Prevented
65 Invalid Height – Check Sensor
Check the voltage out of the height transducer, into
P4-3. It should be between 0.4 V and 4.6 V and
should vary as the platform position varies.
78 Testing HWFS These are not true faults unless they do not clear
the start-up tests should only occur for a short
time.
77 Start Up!
66 Overload Functions Disabled! These are not true faults – the GP102 has been
congured to suppress overload functionality.
67 Factory Override
Always Off Idle Timeout Active!
Action a function to clear the idle timeout if it
occurred. Ensure the GP102 is correctly mounted
– incorrect mounting can cause the bad tilt sensor
diagnostic to occur. Otherwise there may be an
internal problem with the GP102.
71 Fault: Bad Tilt Sensor
72 Fault: Bad HWFS
73 Fault: Bad Slave Analogs
74 Fault: Bad Strain Monitors
75 Fault: Bad Slave Micro
76 Fault HWFS Stalled!
