Skyjack SJ6826RT - 29 Hydraulic Generator Does Not Shut off from Generator Switch

112
SJ6826RT, SJ6832RT
213560ABA
Section 4 – Troubleshooting Information Electrical System
17. Loose or broken wire #43 from Anti-Start Relay 32CR1
to Hydr.Generator Relay 86CCR.
Check continuity. Replace if defective.
18. Loose or broken wire #86D from Hydr.Generator Relay
86CCR to Hydr.Generator Valve solenoid 2H-86D.
Check continuity. Replace if defective.
19. Loose or broken wire #02 from Base terminal block
TB-1 to Hydr.Generator Valve solenoid 2H-86D.
Check continuity. Replace if defective.
20. Defective Hydr.Generator Valve solenoid 2H-86D. Check coil. Replace if defective.
21. Open diode D86D. Check diode. Replace if defective.
22. Loose or broken wire #17B from diode D86D to Base
terminal block TB-1.
Check continuity. Replace if defective.
4.2-29 Hydraulic Generator does not Shut Off from Generator Switch
1. Defective Hydr.Generator switch S12.
Operate switch. Check continuity between wire #09 and
wire #86 when switched to “OFF”.
Replace if defective.
2. Loose or broken wire #86 from Hydr.Generator switch
S12 to diode D86.
Check continuity. Replace if defective.
3. Open diode D86. Check diode. Replace if defective.
4. Loose or broken wire #86A from diode D86 to Hydr.
Generator Stop Relay 86ACR.
Check continuity. Replace if defective.
5. Loose or broken wire #02 from Base terminal block
TB-1 to Hydr.Generator Stop Relay 86ACR.
Check continuity. Replace if defective.
6. Defective Hydr.Generator Stop Relay 86ACR. Check relay. Replace if defective.
