160
SJ6826RT, SJ6832RT
213560ABA
Section 5 – Procedures Outriggers
Adjustments Menu Options (Factory set - non adjustable)
Xtilt TRIP Displays the tilt trip point in the X orientation
Ytilt TRIP Displays the tilt trip point in the Y orientation
TILT ENTRY Displays the tilt delay time
TILT EXIT Displays the tilt delay time
Xlevel TRIP Displays the tilt trip point in the X orientation during the auto-level function
Ylevel TRIP
Displays the tilt trip point in the Y orientation which applies during the auto-level
function
Machine Setup Menu Options (Factory set - non adjustable)
DEFAULTS
Allows all adjustments and machine settings to be set to defaults.
WARNING: All GP106 settings will be changed. Use with caution!
CALIBRATE LEVEL
Allows levelling of the integral tilt sensor of the GP106, when the vehicle is positioned
on level ground.
TILT MODE
Allows conguration of the GP106 tilt output (P2-9):
1. Output turns on to light lamp when tilted.
2. Output turns off to cutout functions when tilted
3. Output turns off to cutout functions when tilted AND elevated
TILT FILTER
Displays the lter applied to the tilt measurements during the auto-level function (used
to minimize the effect of vehicle vibrations on the tilt measurement).
Xlevel TARGET Displays the tilt in the X orientation at which the auto-level function will complete.
Ylevel TARGET Displays the tilt in the Y orientation at which the auto-level function will complete.
tilt SLACK
Displays the amount of vehicle tilt exceeding the Xtilt TARGET and/or Ytilt TARGET in
which the auto-level function does not attempt to level.
Example: Xtilt TARGET=0.3°, Ytilt TARGET=0.7°, tilt SLACK=0.5°
If machine is tilted to 1.0° in the X and Y orientations, the auto-level function will
attempt to level the X orientation (0.3+0.5<1.0) but does not attempt to level the Y
orientation (0.7+0.5>1.0)
RANGE: 0.0° to 1.0°, default 0.3°
