P
RIORITY
C
OMMANDS
3-129
• cos-value - Class-of-Service value (Range: 0-7)
Default Setting
The list below shows the default priority mapping.
Command Mode
Interface Configuration (Ethernet, Port Channel)
Command Usage
• The precedence for priority mapping is IP Port, IP Precedence or IP
DSCP, and default switchport priority.
• IP Precedence values are mapped to default Class of Service values on
a one-to-one basis according to recommendations in the IEEE 802.1p
standard, and then mapped to the queue defaults.
• This command sets the IP Precedence for all interfaces.
Example
The following example shows how to map IP precedence value 1 to CoS
value 0:
IP Precedence Value CoS Value
00
11
22
33
44
55
66
77
Console(config)#interface ethernet 1/5
Console(config-if)#map ip precedence 1 cos 0
Console(config-if)#
