VLAN C
ONFIGURATION
2-45
• Maximum Number of Supported VLANs – Maximum number
of VLANs that can be configured on this switch.
Web – Click VLAN/VLAN Basic Information.
CLI – Enter the following command.
Displaying Current VLANs
Command Attributes for Web Interface
• VLAN ID – ID of configured VLAN (1-4094, no leading zeroes).
• Up Time at Creation – Time this VLAN was created; i.e., System
Up Time.
• Status – Shows how this VLAN was added to the switch.
- Dynamic GVRP: Automatically learned via GVRP.
- Permanent: Added as a static entry.
• Tagged Ports – Shows the tagged VLAN port members.
• Untagged Ports – Shows the untagged VLAN port members.
Console#show bridge-ext 3-108
Max support vlan numbers: 255
Max support vlan ID: 4094
Extended multicast filtering services: No
Static entry individual port: Yes
VLAN learning: IVL
Configurable PVID tagging: Yes
Local VLAN capable: No
Traffic classes: Enabled
Global GVRP status: Enabled
GMRP: Disabled
Console#
