M
ULTICAST
C
ONFIGURATION
2-75
Displaying Interfaces Attached to a Multicast Router
Command Attributes
• VLAN ID – ID of configured VLAN (1-4094).
• Multicast Router List – Multicast routers dynamically discovered
by this switch or those that are statically assigned to an interface on this
switch.
Web – Click IGMP/Multicast Router Port Information. Select the
required VLAN ID from the scroll-down list to display the associated
multicast routers.
CLI – This example shows that Port 11 has been statically configured as a
port attached to a multicast router.
Specifying Interfaces Attached to a Multicast Router
Depending on your network connections, IGMP snooping may not always
be able to locate the IGMP querier. Therefore, if the IGMP querier is a
known multicast router/switch connected over the network to an interface
Console#show ip igmp snooping mrouter vlan 1 3-119
VLAN M'cast Router Port Type
---- ------------------ -------
1 Eth 1/11 Static
