C
LASS
OF
S
ERVICE
C
ONFIGURATION
2-53
Web – Click VLAN/VLAN Port Configuration or VLAN Trunk
Configuration. Fill in the required settings for each interface, click “Apply.”
CLI – This example sets port 1 to accept only tagged frames, assigns
PVID 3 as the native VLAN ID, enables GVRP, sets the GARP timers,
and then sets the switchport mode to hybrid.
Class of Service Configuration
Class of Service (CoS) allows you to specify which data packets have
greater precedence when traffic is buffered in the switch due to
congestion. This switch supports CoS with four priority queues for each
port. Data packets in a port’s high-priority queue will be transmitted before
those in the lower-priority queues. You can set the default priority for each
interface, and configure the mapping of frame priority tags to the switch’s
priority queues.
Console(config)#interface ethernet 1/1 3-68
Console(config-if)#switchport acceptable-frame-types tagged 3-98
Console(config-if)#switchport ingress-filtering 3-99
Console(config-if)#switchport native vlan 3 3-100
Console(config-if)#switchport gvrp 3-104
Console(config-if)#garp timer join 10 3-106
Console(config-if)#garp timer leave 90 3-106
Console(config-if)#garp timer leaveall 2000 3-106
Console(config-if)#switchport mode hybrid 3-97
Console(config-if)#
