M
AIN
M
ENU
2-5
Main Menu
Using the onboard Web agent, you can define system parameters, manage
and control the switch, and all its ports, or monitor network conditions.
The following table briefly describes the selections available from this
program.
Menu Description Page
System
System Information Provides basic system description, including
contact information
2-8
IP Sets the IP address for management access 2-10
Passwords Assigns a new password for the logon user name 2-13
Radius Configures RADIUS authentication parameters 2-14
Firmware Manages code image files 2-16
Configuration Manages switch configuration files 2-18
Reset Restarts the switch
Bridge Extension Shows the configuration for bridge extension
commands; enables GVRP multicast protocol
2-20
Switch Information Shows the number of ports, hardware/firmware
version numbers, and power status
2-22
Port
Port Information Displays port connection status 2-24
Trunk Information Displays trunk connection status 2-24
Port Configuration Configures port connection settings 2-26
Trunk Configuration Configures trunk connection settings 2-26
Broadcast Storm
Protect Configuration
Sets the broadcast storm threshold for each port 2-28
Mirror Sets the source and target ports for mirroring 2-29
