VLAN C
ONFIGURATION
2-41
Web – Click STA/STA Port Configuration or STA Trunk Configuration.
Modify the required attributes, then click “Apply.”
CLI – This example sets STA attributes for port 5.
VLAN Configuration
In conventional networks with routers, broadcast traffic is split up into
separate domains. Switches do not inherently support broadcast domains.
This can lead to broadcast storms in large networks that handle traffic
such as IPX or NetBeui. By using IEEE 802.1Q-compliant VLANs, you
can organize any group of network nodes into separate broadcast domains,
thus confining broadcast traffic to the originating group. This also
provides a more secure and cleaner network environment.
An IEEE 802.1Q VLAN is a group of ports that can be located anywhere
in the network, but communicate as though they belong to the same
physical segment.
Console(config)#interface ethernet 1/5 3-68
Console(config-if)#bridge-group 1 priority 0 3-89
Console(config-if)#bridge-group 1 path-cost 50 3-88
Console(config-if)#bridge-group 1 portfast 3-90
