MV-32/64 Multiviewer www.snellgroup.com Maintenance Tasks
Issue 1 Rev 11 Page 104 © 2014 Snell Limited
6.2.1 Backing Up a Multiviewer XML Layout File
1. Use a client FTP program such as “FileZilla” or “SmartFTP” to open an FTP
connection to the multiviewer.
Default Multiviewer IP Address: ftp://192.168.0.120
(ftp://192.168.0.121 for second CPU in an MV-32 dual frame)
Username: root
Password: smv
2. From the Layouts directory (located in the Root directory) select the .XML layout file
and copy it to the PC desktop or wherever the file is to be stored.
3. The file transfer will begin.
4. When the download is complete close FTP program.
6.2.2 Restoring an XML Layout file to a Multiviewer
1. Use a client FTP program such as “FileZilla” or “SmartFTP” to open an FTP
connection to the multiviewer.
Default Multiviewer IP Address: ftp://192.168.0.120
(ftp://192.168.0.121 for second CPU in an MV-32 dual frame)
Username: root
Password: smv
2. Open the Layouts directory (located in the Root directory) and copy the .XML layout
file to the Layouts directory.
3. The file transfer will begin.
4. When the file transfer is complete, the uploaded XML layout file will be available to
use in the Load Layout list.
5. Click on the Load Layout button, select the uploaded layout and click on the OK
button. The layout will be loaded.
6. At this point the layout has only been loaded into the Java applet and will not be
displayed on the multiviewer output screen.
7. Click on the Update Layout button to transfer the layout to the multiviewer display
output screen.
