MV-32/64 Multiviewer www.snellgroup.com Operation

4.11.4 Audio Monitor Outputs Tab

4.11.5 External Audio Outputs Tab

Fig 30. Module Menu - Audio Monitor Outputs Tab.

Output 1 to 8

Audio monitor output channel selection controls. Select the source

and source channel number to be directed to the monitor output.

Table 20. Module Menu - Audio Monitor Outputs Tab.

Fig 31. Module Menu - External Audio Outputs Tab.

Output 1 to 32

Audio output channel selection controls. Select the source and

source channel number to be directed to the output.

Table 21. Module Menu - External Audio Outputs Tab.
