MV-32/64 Multiviewer www.snellgroup.com Connection to Other Equipment
Issue 1 Rev 11 Page 101 © 2014 Snell Limited
5.5.3 MV-32/MV-64 Settings for RS 422 and TCP/IP Connections
• Configure the Multiviewer inputs in the Snell Router Network tab
(see section 4.11.11.2):
(Setup Module > Protocols tab > Snell Router Network tab > Video Router tab)
MV
Inputs
Matrix
N
o.
Matrix
Level
Router Destination Router Association
Connected
Tick Box
MV BNC
Input
10
As required.
Destinations start at 0
As required.
Destinations start at 0
Tick to enable
polling of Router
designations for
status changes
or background
updates if
connection is lost
MV BNC
Input
10
As required.
Destinations start at 0
As required.
Destinations start at 0
MV BNC
Input
10
As required.
Destinations start at 0
As required.
Destinations start at 0
Table 60. MV-32/MV-64 Video Router Tab Settings.
