MV-32/64 Multiviewer www.snellgroup.com Technical Appendix
Issue 1 Rev 11 Page 125 © 2014 Snell Limited
B.2 Backup Power Supply
Item Description
Front 2x Green LED indicator for presence of AC input and DC output per
supply fitted
Rear 1 x 2-pole DC power outlet socket
3 x IEC AC power socket (one for each supply that can be fitted)
25 way D-type (CN500) into which supplied d-type shell MUST be
fitted for DC output to be active
AC power switch
Mechanical 1U Power Supply
Outline Dimensions: 484mm(W) x 351mm(D) x 44mm(H)
Weight: up to 11kg with three PSUs fitted (one supplied as standard)
Power Auto-sensing 90 - 264 V AC, 50/60Hz switch mode 1kW power
supply with 24V DC single rail output.
Table 76. Backup Power Supply.
