5.5.1.4 Nebula Settings
• Use the Nebula editor to configure the Nebula RS485-1 or RS485-2 serial port.
5.5.2 TCP/IP Network Connection
5.5.2.1 Nucleus2 2463 Settings
Changes made to the Nucleus2 2463 router control module database configuration must be
pushed from Workbench to the router controller to make the controller use the new
configuration. In a dual controller router changes must be copied to the second controller and
the database must be pushed to both controllers (idle controller first, see the router manual
for full details).
Use Workbench to configure an IP port on the Nucleus2 2463 router controller.
(Routers > Port Configuration button > New IP Port button)
5.5.2.2 MV-32/MV-64 Settings
• Configure the router controller network details
(Setup Module > Protocols Tab > Snell Router Network Tab > New Button)
Protocol Baud Rate Data Bits Parity Stop Bit
General Remote 38400 8 None 1
Table 57. Nebula Serial Port Configuration
Port
Type
Protocol IP Port Properties
Single/Dual
Controller
Primary IP
Address and
Port
Secondary
IP Address
and Port
IP
General
Remote In
(SW-P-08)
Centra Controller
(2330/246xPC)
Set as router
configuration
Set to the
main router
control
module
IP address
and port
number
Set to the
backup router
control
module IP
address and
port number
(if applicable)
Table 58. Nucleus2 2463 IP Port Configuration.
Setting Description
Dual Controller
Tick this box if there is a main and backup router controller available
in the router. This will allow the IP addresses of both controllers to be
entered.
Name
Enter a suitable name for the router. This will be the name used in the
list of controllers that can be chosen when setting up the router table
(see section 4.11.11.2).
Controller 1
IP address
Enter the IP address of the main router controller in a dual controller
system or just the single controller if only one is present.
Controller 1 Port
Enter the TCP port of the main router controller in a dual controller
system or just the single controller if only one is present.
Controller 2
IP address
Dual Controller Systems only:
Enter the IP address of the backup router controller (if applicable).
Controller 2 Port
Dual Controller Systems only:
Enter the TCP port of the backup router controller (if applicable).
Table 59. MV-32/MV-64 Controller Network Settings.
