Snell MV-32 - Analog Audio Input;Output (Connector 2) Channels 17 to 32; AES;EBU Audio Input;Output Connector 44 Pole Female

MV-32/64 Multiviewer www.snellgroup.com Connection to Other Equipment
Issue 1 Rev 11 Page 85 © 2014 Snell Limited
5.1.5 Analog Audio Input/Output (Connector 2) Channels 17 to 32
The following table gives the pin assignments for channels 17 to 32 for the 44 pole sub-D
female connector number 2.
5.1.6 AES/EBU Audio input/output Connector 44 Pole Female
Female 44 way D connector AES/EBU audio Input/Output assignments channels 1 to 16.
AES/EBU inputs or outputs (depending on the card fitted) may be jumper selected per
channel to be either balanced or unbalanced. The settings are set via jumpers on each digital
audio input card. See section 3.6 for jumper settings.
Channel Number +VE Pin -VE Pin Common GND Pins
17 15 30
31, 32 and 35 to 44
18 14 29
19 13 28
20 12 27
21 11 26
22 10 25
23 9 24
24 8 23
25 7 22
26 6 21
27 5 20
28 4 19
29 3 18
30 2 17
31 1 16
32 33 34
Table 50. Analog Audio input/output Connector 1.
Channel Number +VE Pin -VE Pin Common GND Pins
1 & 2 15 30
1, 24, 10, 33, 19
3 & 4 13 28
5 & 6 11 26
7 & 8 9 24
9 & 10 7 22
11 & 12 5 20
13 & 14 3 18
15 & 16 1 16
Table 51. AES/EBU Audio input/output Connector 44 pole female.
