MV-32/64 Multiviewer www.snellgroup.com Introduction

2.1.2 Audio Input Card Types

Non-embedded external audio sources are supported by dedicated input cards.

• Card Type MV-AIA - analog, 32 channels (16 pairs)

• Card Type MV-AID - Digital, 16 AES/EBU pairs

2.1.3 Audio Output Card Types

Optional audio outputs are supported by dedicated output cards.

• Card Type MV-AOP1A: 32 channel analog audio output

• Card Type MV-AOP1D: 16 AES/EBU pairs audio output

2.1.4 Card Type/Firmware Version Compatibility

The MV-VIP3 and MV-VIP3D cards cannot be mixed with MV-VIP1 or MV-VIP2 cards in a

multiviewer frame because they use different versions of firmware. All cards fitted in a

Multiviewer frame run on the same firmware version and must be compatible with that

firmware version.

The following table gives details of the firmware that each of the card types is compatible with.

Note:

• For audio card rules and limitations see appendix D.1.1 and D.1.1.1.

Note:

• For audio card rules and limitations see appendix D.1.1 and D.1.1.1.

Important:

If MV-VIP3 or 3D cards are to be fitted in a multiviewer frame that contains MV-VIP1 or

MV-VIP2 cards they must first be removed and replaced with MV-VIP3 or 3D cards.

Card Type

Multiviewer

Firmware

Version 2.X.X

Multiviewer

Firmware

Version 3.X.X

Video Input Cards:

MV-VIP3 No Yes

MV-VIP3D No Yes

MV-VIP1 (No longer supplied) Yes No

MV-VIP2 (No longer supplied) Yes No

Audio Input Cards:

MV-AIA Yes Yes

MV-AID Yes Yes

Audio Output Cards:

MV-AOP1A Yes Yes

MV-AOP1D Yes Yes

Table 1. Card Type and Firmware Version Compatibility Table
