Snell MV-32 - Video Card GPI Input;Output Pin Assignments; Analog Audio Input;Output (Connector 1) Channels 1 to 16

MV-32/64 Multiviewer www.snellgroup.com Connection to Other Equipment
Issue 1 Rev 11 Page 84 © 2014 Snell Limited
5.1.3 Video card GPI Input/Output pin assignments
Female 15 way 'D' connector assignments
The following table gives the pin assignments for the 15 way D type connector:
5.1.4 Analog Audio Input/Output (Connector 1) Channels 1 to 16
The following table gives the pin assignments for channels 1 to 16 for the 44 pole sub-D
female connector number 1.
Fig 66. 15 way D type Connector.
Pin Number Signal Pin Number Signal
1 GPI-In 1 9 GPI-In 8
2GPI-In 210 GND
3 GPI-In 3 11 GPI-Out 1
4 GPI-In 4 12 GPI-Out 2
5 GND 13 GPI-Out 3
6 GPI-In 5 14 GPI-Out 4
7GPI-In 615 GND
8GPI-In 7- -
Table 48. Video card GPI Input/Output pin assignments
15
15 11
10
6
Channel Number +VE Pin -VE Pin Common GND Pins
11530
31, 32 and 35 to 44
21429
31328
41227
51126
61025
7924
8823
9722
10 6 21
11 5 20
12 4 19
13 3 18
14 2 17
15 1 16
16 33 34
Table 49. Analog Audio input/output Connector 1.
