Front & Rear Panels
Front Panel • Power supply and fan failure LED indicators on front panel
• 2 x USB-2 ports
Rear Panel • 2 x RJ45 connector for Ethernet (LAN) for browser and NTP
clock update.
MV-32:
LAN-1 - CPU/Buffer card next to the PSU module
LAN-2 - CPU/Buffer card furthest from the PSU module
MV-64:
LAN-1 - CPU/Buffer card next to the PSU module
LAN-2 - not used
• 2 x RS232/RS422 port for UMD tally via TSL, Image Video or
other protocols.
MV-32:
RS422-1 - CPU/Buffer card next to the PSU module
RS422-2 - CPU/Buffer card furthest from the PSU module
MV-64:
RS422-1 - CPU/Buffer card next to the PSU module
RS422-2 - not used
• 2 x USB-2 port
• 1 x IEC AC power socket
• 1 x 2-pole DC power socket
MV-32 connectors:
• 4 x DVI-I ports for digital or analog display - 2 per CPU card
• 2 x BNC for LTC input - 1 per CPU card
• 2 x BNC for video sync input - 1 per CPU card
• 2 x 25 way 'D' connector for audio monitoring out
- 1 per CPU card
• 2 x 26 way 'D' connector GPI I/O port - 1 per CPU card
MV-64 connectors:
• 2 x DVI-I ports for digital or analog display
• 1 x BNC for LTC input
• 1 x BNC for video sync input
• 1 x 25 way 'D' connector for audio monitoring out
• 1 x 26 way 'D' connector GPI I/O port
Table 75. Physical Technical Data
