MV-32/64 Multiviewer www.snellgroup.com Technical Appendix
Issue 1 Rev 11 Page 123 © 2014 Snell Limited
Input/Output Cards
Video MV-VIP3 & MV-VIP3D: composite (limited to 2 inputs per card, inputs
1 and 2), SD-SDI, HD-SDI (up to 3G) 4 x video inputs
MV-VIP1: composite, SD-SDI, DVI-I, S-Video, RGB/YUV 4 x video
inputs
MV-VIP2: composite, SD-SDI, DVI-I, S-Video, RGB/YUV, HD-SDI
(up to 3G) 4 x video inputs
VidLoop: 4 x video loop through (requires two card slots)
Audio MV-AIA: 32 channel analog audio input
MV-AID: 16 AES/EBU pairs digital audio input
AOP1A: 32 channel analog audio output
AOP1D: 16 AES/EBU pairs audio output
Notes:
• Audio cards must be fitted in the slots immediately following
the last populated video card slot.
• Slots 1 and 2 are not compatible with audio cards. If audio
cards are installed a minimum of one video card must be
fitted in slot 1 with a loop through rear panel. This allows the
first audio card to be fitted in slot 3.
• When an MV-32 multiviewer is fitted with a second
CPU/buffer card slots 13 and 14 are not compatible with
audio cards. If audio cards are installed a minimum of one
video card must be fitted in slot 13 with a loop through rear
panel. This allows the first audio card to be fitted in slot 15.
MV-64 only:
• A maximum of 8 audio cards (any mix of input and output)
can be fitted in an MV-64 multiviewer.
• Slots 17 and 18 are reserved for Audio cards but can’t be
used until slots 1 to 16 have been filled.
Table 75. Physical Technical Data
