MV-32/64 Multiviewer www.snellgroup.com Technical Appendix
Issue 1 Rev 11 Page 122 © 2014 Snell Limited
Physical Spec
Mechanical 3U 19" Rack Mounting Frame with removable front panel,
temperature controlled fan assisted ventilation, 20 card slots,
separate rear connector modules and power supply/fan status
indicators.
Two versions:
MV-64: Single multiviewer with up to 64 video inputs
MV-32: Two separate multiviewers, each with up to 32 video inputs
Outline Dimensions: 445mm(W) x 550mm(D) x 132mm(H)
Weight: 19kg (full frame)
Power Auto-sensing 90 - 264 V AC, 50/60Hz switch mode internal power
supply
24V DC Output
Maximum power consumption 712W (16 x video cards + 2 x audio
cards)
Environmental Temperature 0°C to 30°C Humidity 70% max.
Table 75. Physical Technical Data
