MV-32/64 Multiviewer www.snellgroup.com Technical Appendix
Issue 1 Rev 11 Page 120 © 2014 Snell Limited
Signal Inputs (Continued)
Video Loop Through
Option
Video input loop-through: Optional on SD-SDI and HD-SDI. These
are provided on a rear connector panel that occupies two card slots.
Embedded Audio Embedded audio derived from SD-SDI/HD-SDI.
MV-VIP3 & MV-VIP3D: up to 32 channels per source.
MV-VIP1 & MV-VIP2: up to 16 channels per source.
MV-VIP3D cards only:
Dolby E level metering on any SDI embedded audio pair.
Up to four pairs per SDI source can be metered (more if there are
less than eight encoded channels per pair) up to 32 encoded
channels.
External Audio Via optional input cards:
• Analog (in multiples of 32 channels)
• AES/EBU (in multiples of 16 pairs) with SRC (32kHz-96kHz
re-sampled to 48kHz)
LTC SMPTE-12M unbalanced >0.5Vpp
Signal Outputs
Video Video outputs: 2 x DVI-I outputs (analog and digital component) per
multiviewer, supporting resolutions:
• XGA (1024x768@60Hz)
• XGA TG (1024x768@61.067Hz)
• 720p60 (1280x720@60Hz)
• 720p50 (1280x720@50Hz)
• SXGA (1280x1024@60Hz)
• SXGA (1280x1024@50Hz)
• SXGA+ (1400x1050@60Hz)
• 1080p60 (1920x1080@60Hz)
• 1080p50 (1920x1080@50Hz)
Processing delay varies from 2-3 fields for interlaced video inputs,
2-3 frames for progressive video inputs, depending on timing
relationship between the input and output.
Audio 4 pairs of analog audio monitor outputs (with delay compensation)
may be assigned from any audio input/source. Embedded audio may
be demuxed.
Optional output cards for:
• Analog (in multiples of 32 channels)
• AES/EBU (in multiples of 16 pairs)
Item Description
Table 74. Technical Data
