MV-32/64 Multiviewer www.snellgroup.com Operation
Issue 1 Rev 11 Page 79 © 2014 Snell Limited
Example 1:
Trigger the timer to start at 10.00am, stop at 10.30am and countdown beforehand.
• Set the timer mode to Start at a certain time of day, set the Start at and Stop at
times to 10:00:00 and 10:30:00 respectively.
•Tick the Countdown first box. If the current time is 9:45am then the timer will
now be displaying 00:15:00, and be counting down. It will currently be white,
assuming the default colors are set.
• When the time of day is 10 seconds before 10am the timer will change color to
orange and be displaying 00:00:10.
• When 10am is reached it will switch to red and start counting up from 00:00:00.
• When 10:30am is reached it will be displaying 00:30:00. Immediately after that it
will change back to white and start counting down from 23:30:00 - the amount of
time remaining before 10am the next day.
Stop at Only available if the Timer Mode is set to Start at a certain time of day
at the top of the Timer tab.
Stop at (hh:mm:ss) - sets the time of day the timer will stop at.
Where
hh = Hours in 24 hour format
mm = Minutes
ss = Seconds
Font, Font Size The font to use for the digits. If the size is set to auto then the digits will
be sized to fit in the window, up to a certain maximum font size.
Countdown Colour Start at a certain time of day Timer Mode: this is the color of the timer
digits before the Start at time is reached.
Control with GPIs Timer Mode: this is the color of the timer digits while
the GPI has not triggered the timer and while it is counting down.
Transition Colour Start at a certain time of day Timer Mode: this is the color of the timer
digits for the 10 seconds before the Start at time is reached.
Control with GPIs Timer Mode: if the timer is only set to count up then
this is not applicable. If Countdown First is ticked then it will change to
the transition color for the 10 seconds before it reaches 00:00:00.
Destination Colour Start at a certain time of day Timer Mode: this is the color of the timer
digits while the time of day is in between the Start at time and Stop at
time.
Control with GPIs Timer Mode:
• Countdown first ticked: this is the color of the timer digits after
the timer has finished counting down.
• Countdown first not ticked: this is the color that the timer
changes to as soon as the GPI triggers it.
Background Colour Color of the filled background.
Table 45. Edit Object - Properties - Timer Tab.
