Sonatest Wave - 17 Menus and Parameters Reference

100 Wave User Manual
Version 4
17 Menus and Parameters Reference
Cal
Signal
Signal (continued)
● Velocity
● Probe Zero
● Range
● Delay
● Set Ref. Gain
● Ref. Amplitude
● Auto Cal
● Rectification
○ Full
○ +Half
○ -Half
○ RF
● Avg Factor
○ Disable
○ 2
○ 4
○ 8
○ 16
○ 32
● Filter
o 0.5 MHz narrow
o 0.5 MHz wide
o 1 MHz narrow
o 1 MHz wide
o 1.25 MHz narrow
o 1.25 MHz wide
o 2 MHz narrow
o 2 MHz wide
o 2.25 MHz narrow
o 2.25 MHz wide
o 3.5 MHz narrow
o 3.5 MHz wide
o 4 MHz narrow
o 4 MHz wide
o 4.5 MHz narrow
o 4.5 MHz wide
o 5 MHz narrow
o 5 MHz wide
o 7.5 MHz narrow
o 7.5 MHz wide
o 10 MHz narrow
o 10 MHz wide
o 15 MHz narrow
o 20 MHz narrow
o 20 MHz wide
o Broadband low
o Broadband high
• Reject Level
• Reject Type
o None
o Suppressive
o Linear
• Ref. A-Scan
o Hold
o Reset
• Envelope
o Off
o Peak
o Trail
• Reset Envelope
