26 Wave User Manual
Version 4
NOTE: When the screen is frozen, the button appears like this
, indicating the frozen status.
6.4 Screen Capture
The table below describes the behaviour of the Screen Capture button. For more details
see Section 13.2.
Table 7 - Screen capture button behaviour
Button
Action
Takes a complete screenshot of the entire screen, in PNG file format. An
XML file with all settings and measurements will also be created. In addition,
you can name your screenshot, add comments and use a rating system to
identify it.
All parameters related to the screenshot will be saved for use when a report
is created.
6.5 Gates
Wave supports four (4) gates. All can be used simultaneously and all offering all
measurements.
NOTE: The gate to gate measurements are possible between Gate 1
and Gate 2 (G1-G2), and between Gate 3 and Gate 4 (G3-G4).
6.5.1 Enabling a Gate
There are two distinct ways to enable and to set the gates. It is directly related to the
selected mode view in the instrument. They are detailed below.
