19 Quality Assurance

Wave was designed to meet and to surpass several international standards. All Wave

units are tested for quality assurance before delivery to customers.

The following list shows the standards that Wave has been tested for:

• EN 12668

• EN 61326-1

• FCC Part 15

• ICES 003

• CISPR11

• IEC 61000-4
