Wave User Manual 15
Version 4
Figure 7 – GPIO connector pinouts
The following table presents information regarding the part number of the GPIO.
Table 4 – GPIO part number
K Series (1K), 16-pin, receptacle, centre key (G),
watertight
K Series (1K), 16-pin, straight plug, centre key
(G)
3.6 The Expansion Port
The expansion port is a Sonatest proprietary connection that will allow adding extra
accessories. The protector cap over the expansion port must remain in place to protect
the connector. It should only be removed when attaching an accessory.
3.7 The USB-C Connector
The USB-C connector can be found on the left side (front view) of the instrument. It is
protected and lies behind a small door made of soft material.
