Wave User Manual 69
Version 4
Figure 50 – API K factor calculated after the calibration
View the following video for how to perform an API calibration.
12.6.2 API Sizing Option
To calibrate the API, only one sizing option is available.
Table 26 – API sizing option
The transfer loss is the gain to compensate for the difference of
attenuation between a reference standard and the part to be inspected
12.7 T-log
The method to log thickness data, the T-log (also known as Thickness logging), enables
you to log several thickness measurements in a table. These values are colour-coded
based on different thresholds (Min Threshold, Max Threshold, Tolerance).
The T-log is built using a wizard. The first step enables you to define the grid. The second
step allows you to record thickness measurements.
View the following video for how to use T-log.
