12.7.1 Parameter descriptions
The following table describes the grid’s parameters.
Table 27 – Grid parameters
Button
Choices
Action
Grid Width
1 to 200 cells
Determines the width of the grid
Grid Height
1 to 200 cells
Determines the height of the grid
Min
Threshold
Depends on the selected measurement
Determines the cell’s colour
Max
Threshold
Depends on the selected measurement
Determines the cell’s colour
Tolerance
Depends on the selected measurement
Determines the cell’s colour
The following table describes the parameters with respect to data acquisition.
Table 28 – Data acquisition parameters
Button
Choices
Action
Store
No option available
Save the first measurement in the measurement bar
from the left-hand side
Increment
Order
Right Down, Left Down,
Right Up, Left Up, Down
Right, Down Left
How to move into the grid
T-min
On or Off
This keeps a record of the first minimum value (using
the left-hand side of the measurement bar, this
mode will only be used on the first measurement).
Reset T-min
No option available
Enables you to reset the T-min value
Clear
No option available
Deletes all values in the grid. Important: You need to
perform a long press to activate the button.
Save to CSV
No option available
To save the grid in .csv format as well as other
measurements in the measurement bar.
