Sonatest Wave - 10.2 Weld Types

Wave User Manual 51
Version 4
system (see Section 7.5). A checkbox indicates that this part dimension is visible for
a given part.
Table 17 - Part types and their dimensions available
Flat part
Curved part
T-joint
Corner joint
Thickness
X
X
Horizontal thickness
X
X
Vertical thickness
X
X
Joint height
X
X
Part angle
X
Curved base
X
Outside diameter
X
Inside diameter
X
NOTE: For the Curved type, the Inside Diameter is automatically
calculated. It is therefore impossible for you to modify it. It is a read-
only parameter. That is why it is always greyed out.
10.2 Weld Types
There are twelve (12) weld types, including None:
Square Groove
Single V
