104 Wave User Manual
Version 4
Alarms (continued)
Alarms (continued)
● Alarm 1 GPO
○ None
○ 0
○ 1
○ 2
○ 3
● Alarm 2 GPO
○ None
○ 0
○ 1
○ 2
○ 3
● Alarm 3 GPO
○ None
○ 0
○ 1
○ 2
○ 3
● Alarm 4 GPO
○ None
○ 0
○ 1
○ 2
○ 3
Gate 1
Gate 2
Gate 3
● G1 Enabled
○ Yes
○ No
● G1 Start
● G1 Width
● G1 Level
● G1 Polarity
○ Absolute
○ Positive
○ Negative
● G2 Enabled
○ Yes
○ No
● G2 Start
● G2 Width
● G2 Level
● G2 Polarity
○ Absolute
○ Positive
○ Negative
● G2 Adaptive Triggering
○ On
○ Off
● G2 Blanking
● G3 Enabled
○ Yes
○ No
● G3 Start
● G3 Width
● G3 Level
● G3 Polarity
○ Absolute
○ Positive
○ Negative
