RX Mode: Pulsing Mode
S1 (mm or in): Weld depth of the bevel #1
S2 (mm or in): Weld depth of the bevel #2
TCG: Time corrected gain
Transfer loss (dB): dB loss due to surface conditions, poor coupling, etc.
X-Offset (mm or in): Distance between the front of the probe and the exit point.
